Figure 1. Structural diagram of BBCube 3D (IMAGE)

Tokyo Institute of Technology

Figure 1. Structural diagram of BBCube 3D

Caption

The proposed technology uses a stacked design where processing units (xPU) sit atop multiple interconnected memory layers (DRAM). By replacing wires with through-silicon vias (TSVs), the lengths of the connections can be shortened, leading to better overall electrical performance.

Credit

Profesor Takayuki Ohba

Usage Restrictions

Credit must be given to the creator. Only noncommercial uses of the work are permitted. No derivatives or adaptations of the work are permitted.

License

CC BY-NC-ND
