Microscope Images

Caption

The above terahertz SNOM image shows electrical field concentration (the brighter color) and asymmetry (the bright vs dark color on two sides), indicating a connectivity issue. The below transmission electron microscopy image confirms the disconnect in the junction (the spatial gap).

Credit

U.S. Department of Energy Ames National Laboratory

Usage Restrictions

Credit to U.S. Department of Energy Ames National Laboratory

License

Original content
