Modulation performances of plasmonic metafiber EOMs. (IMAGE)
Caption
a, Experimental setups for direct current (DC) and alternative current (AC) modulation characterizations, which consist of a light source, a metafiber EOM, a signal generator with a voltage amplifier and an optical detector. Depending on DC or AC modulation tests, the light source could be selected as either a super continuum laser (SLS) or a tunable telecoms laser (TL), the signal generator uses either static bias voltages or radio frequency (RF) bit signals, and the optical detector is either an optical spectrum analyzer (OSA) or a fast oscilloscope with photodetector (OPD). The EOM block consists of three layers: plasmonic metasurfaces (bottom layer), EO polymer (middle layer) and a uniform Au film (top layer), which are integrated on the endface of a single mode optical fiber jumper (SMFJ). b, DC modulation performance of the plasmonic metafiber EOM. The reflection spectrum of plasmonic metafiber undergoes a redshift when the DC bias voltage changes from -100 V (green line) to +100 V (red line). The inset shows a modulation depth of 11% at the wavelength of 1287 nm. c, AC modulation performances of plasmonic metafiber EOM at different driving frequencies. Top row shows the temporal responses of an oscilloscope under a constant bias voltage of ±1 V; the bottom row shows the temporal responses of an oscilloscope with nearly the same amplitude of output signals.
Credit
bu Lei Zhang, Xinyu Sun, Hongyan Yu, Niping Deng, FengQiu, Jiyong Wang, Min Qiu
Usage Restrictions
Credit must be given to the creator.
License
CC BY
