Figure 1 Robotic pendant drop for fully-automated light scattering. (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Figure 1 Robotic pendant drop for fully-automated light scattering.

Caption

(a) SA-XPCS measurement on the pendant drop setup at Beamline 8-ID-I, Advanced Photon Source. The inset on the left shows the comparison of the XPCS results from the pendant drop and the reference setups, and the inset on the right shows a zoom-in optical image of the drop hanging from the pipette tip during the measurement. The red laser is used for coarse aligning of the x-ray beam in the vertical direction. (b) ‘Digital Twin’ of the robotic pendant drop setup in Nvidia Isaac simulation, where the electronic pipette is docked on the mounting plate for x-ray measurements. The red lines and arrows indicate the incoming and scattered x-ray beams. The items labeled in the figure are: 1. Robotic arm; 2. Electronic pipette; 3. Mounting plates; 4. Robotic tool changer; 5. Reflective mirror with 1 mm diameter x-ray passthrough; 6. Optical microscope and camera system; 7. Sample preparation station with PCR plates and pipette tips. (c) The robotic pendant drop setup in the adjacent chemical laboratory of the Beamline 8-ID-I, where the electronic pipette is shown picking up a fresh pipette tip for liquid handling. The inset on the top right shows the suspended pendant drop captured by the inline optical system.

Credit

by Qingteng Zhang

Usage Restrictions

Credit must be given to the creator.

License

CC BY
