Inside one of the cavity vacuum chambers (IMAGE)

DOE/SLAC National Accelerator Laboratory

Inside one of the cavity vacuum chambers

Caption

A top-down view of one of the cavity vacuum chambers. Two diamond mirrors can be seen in the upper and lower left corners, each one mounted on four motors that control its angle and position. At upper right, the precision diamond grating that brings X-ray pulses into the chamber is mounted on a screen holder.

Credit

Diling Zhu/SLAC National Accelerator Laboratory
